AcquCAM 5G

AcquCAM 5G

  • USB 3.0 Color Camera
  • 2/3 ” Pregius Sensor
  • 2448 x 2048 pixel
  • Trigger input and I/O
  • Acquisition of images with sufficient contrast
  • High Sensitivity Sensor
  • Fast, seamless image transfer
  • Available of images with a very wide field of view
  • Low Noise Sensor
Product AcquCAM 5G

AcquCAM 5G color camera has a USB 3.0 interface and is the perfect solution for many industrial automation, quality assurance, security, surveillance and medical applications. The color camera ships with the very sensitive 2/3 inch CMOS Pregius  sensor. With up to 38 images per second, the AcuqCAM 5G is a low cost, yet highly versatile imaging solution. The camera includes a C to CS mount adapter, making it compatible to C and CS mount lenses. Using the optional CS to M12 board lens adapter, the camera is
also compatible to M12 board lenses.

Images with AcquCAM 5G

Camera : AcquCAM 5G, Filter Set : JNO-U(B), B(B), G(B)
Sample : bovine pulmonary artery endothelial cell, BPAEC Filter Set : JNO-U(B), B(B), G(B) Camera : AcquCAM 5G C-mount adapter : 1X Lens : UPLNAPO40X Above three images are merged and processed using ARM S/W

Specification

SpecDescription
Size2/3 inch
ResolutionH: 2448, V: 2048
Pixel sizeH: 3.45 µm, V: 3.45 µm
Video formats& Frame rate2448×2048 RGB64 @ 38 fps
2448×2048 RGB32 @ 35 fps
2448×2048 Y16 @ 37 fps                             2448×2048 Y411 @ 38 fps
2448×2048 YUY2 @ 37 fps
Dynamic range8 / 12 bit
Exposure time25 ㎲ to 4s
Lens mountC/Cs mount
InterfaceUSB 3.0
Power supply4.5 to 5.5 VDC
DimensionsH: 29 mm, W: 29 mm, L: 43 mm
Mass65g

More images with AcquCAM 5G

Camera : AcquCAM 5G, Filter Set : JNO-U(B), B(B), G(B)
Sample : bovine pulmonary artery endothelial cell, BPAEC Camera : AcquCAM 5G, Filter Set : JNO-U(B), B(B), G(B) Objective lens : PlanApo60xWLSM, C-mount adapter : 1X Above three images are merged and processed using JNO-ARM
Camera : AcquCAM 5G, Filter Set : JNO-U(B), B(B), G(B)
Sample : bovine pulmonary artery endothelial cell, BPAEC Filter Set : JNO-U(L), B(L), G(L) Camera : AcquCAM 5G C-mount adapter : 1X Lens : UPLNAPO40X Above three images are merged and processed using ARM S/W
